With a long proven track record, our full range of products helps assert the first market penetration rate in the air compressor industry
Product mix: over 100 products are classified as fixed and portable; air cooling and water cooling; and diesel and electric drive.
Parameters of Piston Air Compressors for Mining and Engineering | ||||
Model | Supporting power (kW) | Displacement（m3/min) | Discharge pressure (MPa) | Dimensions (L×W×H) (mm) |
W-1.35/5-D | 11 | 1.35 | 0.5 | 1,390×640×980 |
W-1.35/5 | S1100 | 1.35 | 0.5 | 1,390×640×980 |
W-1.8/5-J-D | 11 | 1.8 | 0.5 | 1,700×710×1,000 |
W-1.8/5-J | S1100 | 1.8 | 0.5 | 1,700×710×1,000 |
W-1.8/5-D | 11 | 1.8 | 0.5 | 1,700×710×1,000 |
W-1.8/5 | S1100 | 1.8 | 0.5 | 1,700×710×1,000 |
W-2/5-D | 11 | 2 | 0.5 | 1,700×810×1,050 |
W-2/5 | S1100 | 2 | 0.5 | 1,700×810×1,050 |
W-2.6/5-D | 15 | 2.6 | 0.5 | 1,780×870×1,235 |
W-2.6/5 | S1110 | 2.6 | 0.5 | 1,780×870×1,235 |
W-2.8/5-D | 15 | 2.8 | 0.5 | 1,780×870×1,235 |
W-2.8/5 | S1110 | 2.8 | 0.5 | 1,780×870×1,235 |
W-2.8/5-G-D | 15 | 2.8 | 0.5 | 1,780×870×1,235 |
W-2.8/5-G | S1115 | 2.8 | 0.5 | 1,780×870×1,235 |
W-2.8/5-G-DZ | 15 | 2.8 | 0.5 | 1,780×870×1,235 |
W-3/5-D | 18.5 | 3 | 0.5 | 1,800×900×1,300 |
W-3/5 | S1115 | 3 | 0.5 | 1,800×900×1,300 |
2V-3.5/5-D | 18.5 | 3.5 | 0.5 | 1,800×950×1,300 |
2V-3.5/5 | S1125 | 3.5 | 0.5 | 1,800×950×1,300 |
2V-4/5-D | 18.5 | 4 | 0.5 | 1,800×950×1,300 |
2V-4/5 | S1125 | 4 | 0.5 | 1,800×950×1,300 |
W-1.8/7-D | 11 | 1.8 | 0.7 | 1,100×820×1,100 |
W-1.8/7 | S1100 | 1.8 | 0.7 | 1,100×820×1,100 |
W-2.6/7-D | 15 | 2.6 | 0.7 | 1,800×870×1,235 |
W-2.6/7 | S1115 | 2.6 | 0.7 | 1,800×870×1,235 |
W-3.2/7-D | 18.5 | 3.2 | 0.7 | 1,920×960×1,350 |
W-3.2/7 | S1125 | 0.7 | 0.7 | 1,920×960×1,350 |
W-2.5/3-D | 11 | 2.5 | 0.3 | 1,780×870×1,235 |
W-2.5/3 | S1110 | 2.5 | 0.3 | 1,780×870×1,235 |
VF-3/7 | 18.5 | 3 | 0.7 | 1,720×1,100×1,110 |
VF-6/7 | 37 | 6 | 0.7 | 2,100×1,100×1,110 |
VFY-6/7 | 37 | 6 | 0.7 | 2,830×1,500×1,890 |
VF-7/7 | 40 | 7 | 0.7 | 2,100×1,100×1,110 |
CVF7/7 | YC4108 | 7 | 0.7 | 2,760×1,200×1,460 |
CVF7/7 | QC4110 | 7 | 0.7 | 2,760×1,200×1,460 |
VFY-7/7 | 40 | 7 | 0.7 | 2,830×1,500×1,890 |
CVFY-7/7 | YC4108 | 7 | 0.7 | 2,830×1,300×1,890 |
CVFY-7/7 | QC4110 | 7 | 0.7 | 2,830×1,300×1,890 |
VF-9/7 | 55 | 9 | 0.7 | 2,460×1,200×1,220 |
VFY-9/7 | 55 | 9 | 0.7 | 2,830×1,500×1,900 |
VF-10/7 | 63 | 10 | 0.7 | 2,460×1,200×1,220 |
VFY-10/7 | 63 | 10 | 0.7 | 2,830×1,500×1,900 |
CVF-10/7 | YC4108ZG | 10 | 0.7 | 3,200×1,350×1,650 |
CVF-10/7 | QC4112 | 10 | 0.7 | 3,200×1,350×1,650 |
CVFY-10/7 | YC4108ZG | 10 | 0.7 | 3,200×1,550×2,230 |
CVFY-10/7 | QC4112 | 10 | 0.7 | 3,200×1,550×2,230 |
VF-13/7 | 75 | 13 | 0.7 | 2,460×1,200×1,220 |
VFY-13/7 | 75 | 13 | 0.7 | 2,830×1,500×1,900 |
CVF-13/7 | YC6108ZG | 13 | 0.7 | 3,300×1,350×1,470 |
CVF-13/7 | CUMMINS 6BT5.9-C118 | 13 | 0.7 | 3,300×1,350×1,470 |
CVF-13/7 | QC6112 | 13 | 0.7 | 3,350×1,350×2,100 |
CVFY-13/7 | YC6108ZG | 13 | 0.7 | 3,500×1,600×2,640 |
CVFY-13/7 | CUMMINS 6BT5.9-C118 | 13 | 0.7 | 3,500×1,600×2,340 |
CVFY-13/7 | QC6112 | 13 | 0.7 | 3,570×1,600×2,640 |
2V-6/7 | 37 | 6 | 0.7 | 1,750×1,100×1,200 |
2V-7/7 | 40 | 7 | 0.7 | 1,750×1,100×1,200 |
